High-Pressure Heavy Lifting Airbags
Datos del producto:
Lugar de origen: Qingdao, China
Nombre de la marca: Luhang
Certificación: ISO14409
Número de modelo: Bolsas de aire de elevación pesada
Pago y Envío Términos:
Cantidad de orden mínima: 1 por ciento
Precio: Negociable
Detalles de empaquetado: Película en palllet
Tiempo de entrega: 10 ~ 15 días laborables
Condiciones de pago: L/C, D/A, D/P, T/T, Western Union, Moneygram
Capacidad de la fuente: 100pcs/mes
Contacto
Descripción detallada del producto
Nombre del producto: Airbags de elevación pesada de alta presión Material: Caucho mixto con caucho natural y carbono
Color: Negro Tamaño: Ruquirement del cliente
Uso: Lanzamiento del barco, bolsas de elevación marina de goma de buques Embalaje: PALETA
Certificación: CCS,ABS,BV,LR Presión de trabajo: 0.05MPA-0.25MPA

Heavy Lifting Marine Rubber Airbags

Heavy Lifting Marine Rubber Airbags are essential equipment for marine operations, mainly used in ship launching/landing, heavy cargo lifting and moving, as well as salvage and buoyancy assistance. Composed of outer rubber layer, inner rubber layer and synthetic tire cord layer, they boast high load-bearing capacity, enabling them to handle ships up to 10,000 tons and hundreds of tons of heavy goods. With excellent aging resistance and wear resistance, these airbags are flexible and reliable—they require no large machinery, are less restricted by sites, and can be reused, effectively shortening project cycles and reducing costs, thus widely recognized in the global shipbuilding and port construction industries.

High-Pressure Heavy Lifting Airbags 0


Solution Advantages

Saving

Moving caisson with airbags can cut off 70% budget comparing with trolley method.



Safe

Airbags have big contact area with transported object, the low reaction force is good for structure safety.



Convenient

Air bags can move structure strightly in line or steer structure to anywhere.



Specification and Model



You can choose the required diameter and effective length to meet your projects. The below specification only is our standard specification arrange. Other specifications high-pressure heavy lifting airbags also can be supplied upon clients' request.



Air Bag Parameter High-pressure Heavy Lifting Airbags Size
Product Name ship launching marine rubber airbags
Airbags Diameter (m) 0.8 ~ 2.5m, or customized diameter
Effective Length (EL) 6 ~ 25m, or customized length
Total Length (TL) 7 ~ 27m, or customized length
Loading Capacity 10 ~ 40 ton/m, or customized capacity
Model of Airbags QP-ordinary, QG-high-bearing, QS-superhigh bearing

Heavy lifting airbags are categorized by the following three types according to the bearing capacity, per meter in length. We define the number of layers, which means the number of Synthetic-tyre-cord layers, in order to confirm the Safety Working Pressure. Another type is available upon clients' request.

01


QP

Ordinary airbag - with 3, 4 or 5 layers of cord fabric.


02


QG

High-bearing capacity airbag - with 6, 7, or 8 layers of cord fabric.


03

QS

Superhigh-bearing capacity airbag - with 9, 10, or more layers of cord fabrics as a custom request.



Products details

High-Pressure Heavy Lifting Airbags 1

High-Pressure Heavy Lifting Airbags 2High-Pressure Heavy Lifting Airbags 3High-Pressure Heavy Lifting Airbags 4High-Pressure Heavy Lifting Airbags 5

            Cord Fabric                           Air Inlet End                        Air Inlet End                 Air Tightness Swivel End

airbag Application



High-Pressure Heavy Lifting Airbags 6High-Pressure Heavy Lifting Airbags 7High-Pressure Heavy Lifting Airbags 8

                 Ship Launching                                           Ship Lifting                                                 Buoyancy Support



High-Pressure Heavy Lifting Airbags 9High-Pressure Heavy Lifting Airbags 10High-Pressure Heavy Lifting Airbags 11

                     Heavy Lifting                                        Pipeline Buoyancy Airbag                                Marine Salvage



Airbag production process
